A Complete Guide to Forging

1. What Is Forging?

Forging is a metalworking process that applies compressive forces to metal blanks using forging machines, causing plastic deformation to achieve desired shapes, dimensions, and mechanical properties. It is one of the two main branches of metal forming — forging and stamping.

Forging eliminates the casting defects such as porosity and segregation formed during metal smelting, refines the microstructure, and preserves the continuous metal flow lines, which greatly enhance mechanical strength.

Therefore, most high-stress, high-load components in machinery — such as shafts, gears, and connecting rods — are produced by forging instead of casting.

2. Forging Temperature Classification

The deformation temperature significantly affects the forging process. The recrystallization temperature of steel is about 727°C, but 800°C is commonly used as the dividing line:

l Hot Forging: Above 800°C — used for most industrial forgings.

l Warm Forging: Between 300°C–800°C — improves material utilization and reduces machining costs.

l Cold Forging: At room temperature — suitable for precision parts like automotive and mechanical components.

Hot forging is the most common, while warm and cold forging are increasingly popular for precision forming and energy efficiency in modern manufacturing.

3. Types of Forging Processes

Forging can be categorized by temperature and forming mechanism:

(1) Open-Die (Free) Forging

In free forging, a metal blank is deformed between flat or simple-shaped dies under pressure without enclosing it entirely. It’s mainly used for small-batch production of large or simple-shaped parts.

Basic operations include upsetting, drawing-out, piercing, bending, twisting, shifting, and forging welding. Free forging is typically performed as hot forging and uses equipment such as forging hammers or hydraulic presses.

(2) Closed-Die (Impression-Die) Forging

In die forging, the metal is placed in a cavity (die) that has the shape of the final part. Under pressure, the metal flows and fills the die cavity.

There are two subtypes:

l Open-die forging

l Closed-die forging (with or without flash)

Closed-die forging offers higher material utilization, better dimensional accuracy, and lower energy consumption. It’s widely used in automotive, aerospace, and machinery industries.

Based on material type, die forging can be divided into:

l Ferrous metal forging (carbon steel, alloy steel)

l Non-ferrous metal forging (copper, aluminum, titanium alloys)

l Powder metallurgy forging

Extrusion processes also fall under die forging and can be divided into heavy metal extrusion and light metal extrusion.

(3) Ring Rolling

Ring rolling uses a ring rolling machine to form seamless rings of various diameters. It’s commonly used to produce automobile hubs, train wheels, bearings, and other ring-shaped parts.

(4) Special Forging Techniques

This includes roll forging, cross-wedge rolling, radial forging, and liquid die forging.

Each serves specific purposes:

l Roll forging: Preforming process that reduces subsequent forming loads.

l Cross-wedge rolling: For manufacturing balls, shafts, and transmission components.

l Radial forging: Used for large shafts, barrels, and stepped components.

l Liquid die forging: Combines the advantages of casting and forging for complex, thin-walled parts.

(5) Forging by Motion Mechanism

Depending on the motion of the dies, forging can also be classified into:

l Rotary forging (swing forging)

l Roll forging

l Cross-wedge rolling

l Ring rolling

l Skew rolling

Computer-controlled rotary forging allows complex shapes and tight tolerances with relatively low forming forces — ideal for parts like turbine blades.

4. Forging Equipment and Deformation Control

Forging machines can be classified according to deformation control characteristics:

l Load-limited: Hydraulic presses directly drive the ram.

l Stroke-limited: Mechanical presses with crank-link mechanisms.

l Energy-limited: Screw and friction presses using kinetic energy.

l Quasi-stroke limited: Hydraulic-driven crank presses.

Precision control of ram movement, position, and force is crucial for achieving accurate dimensions and prolonging die life. Adjustments in guiding clearance, rigidity, and auxiliary motion compensation are often necessary.

5. Materials Used in Forging

Common forging materials include:

l Carbon steels and alloy steels

l  Aluminum, magnesium, copper, and titanium alloys

l Superalloys such as iron-based, nickel-based, and cobalt-based high-temperature alloys

Material forms include bars, ingots, powders, and molten metals:

l Bar stock is used for small to medium forgings with uniform properties.

l Ingots are used for large forgings — they require heavy deformation to refine coarse grains.

l Powder preforms can be hot-forged to produce high-density, high-precision parts.

l Liquid die forging solidifies metal under pressure, ideal for complex thin-walled components.

Proper control of forging ratio, heating temperature, starting and finishing temperature, and deformation rate ensures the best product quality and lower cost.

6. Forging Process Flow

The process flow varies by method, but a typical hot die forging process includes:

①　Cutting billets

②　Heating

③　Preforming (roll forging)

④　Die forging forming

⑤　Trimming

⑥　Punching

⑦　Straightening

⑧　Inspection (dimensional and surface checks)

⑨　Heat treatment (relieve stress, improve machinability)

⑩　Cleaning (remove scale)

⑪　Final inspection (chemical composition, mechanical properties, non-destructive testing)

7. Advantages of Forged Components

Forging improves both mechanical properties and microstructure compared to castings:

l Eliminates porosity, shrinkage, and inclusions.

l Refines grain structure and improves toughness.

l Ensures continuous metal fiber flow following the shape of the component.

l Offers higher strength, ductility, and fatigue resistance.

Forged parts, especially those produced by precision forging, warm extrusion, and cold extrusion, are superior to castings in performance, reliability, and service life.
